DuckIceLake: An Iceberg v3 REST Catalog Proxy on Top of DuckLake

A full Iceberg v2/v3 REST Catalog proxy on top of DuckLake — so standard Iceberg clients speak directly to a DuckLake-backed lakehouse without modification

DuckIceLake is open source: github.com/KellerKev/duckicelake

DuckIceLake is an Iceberg REST Catalog proxy that sits in front of DuckLake — DuckDB’s SQL-native lakehouse format — and materialises DuckLake’s snapshot and schema state into Iceberg-spec manifests on demand. Standard Iceberg clients — PyIceberg, DuckDB’s iceberg extension, Trino, Spark — connect, read rows directly from S3, and write back via register-in-place commits that DuckLake atomically records.

The result: a lightweight, pixi-managed FastAPI stack with a real object store, real STS credential vending, OAuth2 + RBAC, Prometheus observability, and full Iceberg v3 support — including Puffin deletion vectors, row lineage, and the new primitive types.

What This Project Is

#

DuckLake is a compelling lakehouse format: Postgres as the catalog, Parquet on S3 as the data layer, DuckDB as the query engine. DuckIceLake extends it with a full Iceberg REST Catalog API surface, materialising DuckLake’s snapshot and schema state into spec-compliant manifests so any Iceberg client connects without modification.

The two extension paths — Iceberg REST and DuckLake direct — see exactly the same data. A row written through one appears in the other automatically, with the DuckLake HEAD == Iceberg current-snapshot-id identity invariant kept tight throughout.

Business Problems This Showcases

#

Interoperability without migration. Teams running DuckLake who want to connect PyIceberg, Trino, Spark, or any other Iceberg-native client without migrating away from DuckLake’s Postgres-backed catalog.

Iceberg v3 in production today. DuckIceLake ships a monkey-patch shim (pyiceberg_v3.py) that enables full v3 writes end-to-end — deletion vectors, row lineage, and the new primitive types — through both the client and the proxy’s matching Avro emit paths.

Governed, credential-scoped S3 access. The STS vending layer issues per-table MinIO credentials scoped to exactly the data and metadata paths a client needs — no shared root credentials passed to query engines.

Low-cost open lakehouse stack. Everything runs from a single pixi environment — Postgres, MinIO, the REST proxy, and the query clients. The same stack runs locally for development and on a small cloud VM in production.

Standard tooling, no lock-in. Because the REST surface is spec-complete, any conformant Iceberg client works without modification. Switching away from DuckLake as the backing store is an implementation detail behind the proxy — clients never need to change.

The Architecture at a Glance

#

  Iceberg REST client (PyIceberg, DuckDB iceberg ext, Trino, Spark, …)
              │  HTTP (Iceberg OpenAPI v3)
              ▼
       FastAPI proxy (duckicelake.server)  ──▶ Prometheus /metrics
       │     │     │                       ──▶ /healthz /readyz
       │     │     │
       │     │     │  STS AssumeRole (per-table session policy)
       │     │     ▼
       │     │   MinIO STS  ──▶ vended creds (s3.access-key-id, …)
       │     │
       │     │  SQL via DuckDB + ducklake (write conn + read pool)
       │     ▼
       │  Postgres (psycopg pool)
       │     ├── ducklake_*       — schemas, tables, snapshots, stats, deletes
       │     └── duckicelake_*    — properties, tags, branches, partition sidecar
       │
       │  S3 / MinIO (object I/O)
       ▼
   data/<ns>/<tbl>/metadata/
        ├── vN.metadata.json              ── TableMetadata, versioned per commit
        ├── snap-<id>-<uuid>.avro         ── manifest list (one per snapshot)
        ├── <id>-<uuid>-m0-data.avro      ── data manifest
        └── <id>-<uuid>-m1-deletes.avro   ── delete / DV manifest

The proxy is FastAPI with sync endpoints run in uvicorn’s threadpool — blocking I/O (Postgres, S3, DuckDB) does not pin the event loop. The serve-hi task boots 4 workers for production shape.

Everything runs from a single pixi environment.

Real-terminal recording: same Parquet on S3, two extension paths (Iceberg REST and DuckLake direct) reading the same rows. A write via DuckLake direct appears in the Iceberg reader automatically.

The DuckLake Bridge

#

The core challenge is translation: DuckLake tracks snapshots, files, schemas, and statistics in Postgres using its own schema. Iceberg clients expect versioned vN.metadata.json, manifest lists, and per-file Avro manifests on S3.

DuckIceLake’s materialiser (materialize.py) translates DuckLake’s Postgres catalog state into the full Iceberg metadata chain on S3: versioned vN.metadata.json, manifest list, data manifest, and delete manifest when needed. The snapshot id is deterministic — DuckLake HEAD == Iceberg current-snapshot-id — so operations are debuggable and the two extension paths are always in sync.

Eager materialisation via Postgres NOTIFY

#

DuckDB clients can also write directly via the ducklake: extension (INSERT / UPDATE / DELETE) without going through the REST proxy. These commits land in ducklake_snapshot immediately. To keep the Iceberg layer current without waiting for the next LoadTable call, the proxy runs an eager materialisation path:

• An AFTER INSERT trigger on ducklake_snapshot fires NOTIFY duckicelake_snapshot with the new snapshot id.
• src/duckicelake/notify.py runs an async LISTEN loop. One worker per fleet is elected via pg_try_advisory_lock; the others poll and take over if the elected worker dies.
• Each notification resolves the snapshot id to the touched (schema, table) pairs and runs materialize_all() per table — the full S3 metadata chain appears within ~1s, with no LoadTable call required.
• A duckicelake_materialisation_log sidecar tracks done/failed/pending for idempotency and provides an operator-visible audit trail. A startup catch-up scan covers any snapshots that landed during a listener outage.

The lazy LoadTable path remains the correctness floor. Set DUCKICELAKE_DISABLE_NOTIFY=1 to turn off the eager path — readers still get correct data on demand. PostgreSQL is required for this feature (the LISTEN/NOTIFY machinery and pg_try_advisory_lock are Postgres-specific).

Full Iceberg Commit Surface

#

DuckIceLake implements the complete commit-table action set. Every Iceberg action translates to DuckLake SQL:

Partition transforms are handled correctly end-to-end: identity and bucket[N] pass through DuckLake’s stored values; year / month / day / hour are recomputed server-side; truncate[N] is synthesised via a custom transform since DuckLake has no native equivalent. Partition pruning is verified — PyIceberg pushdown reduces file reads correctly.

Iceberg v3: The PyIceberg Shim

#

DuckIceLake ships pyiceberg_v3.py — a targeted monkey-patch that enables full Iceberg v3 writes from PyIceberg today. It vendors the essentials:

• ManifestWriterV3 / ManifestListWriterV3 subclasses
• SUPPORTED_TABLE_FORMAT_VERSION bumped to 3 in both pyiceberg.table.metadata and pyiceberg.table.update
• DataFile.from_args rewired to resolve defaults dynamically (V2-shape records into V3 writers caused IndexError)
• Client-side gates patched in Transaction.upgrade_table_version + _apply_table_update
• v3 primitive types (variant, geometry, geography) added to PyIceberg’s pydantic validator

One call before any RestCatalog operation:

from duckicelake.pyiceberg_v3 import install
install()

V3 writes — including deletion vectors, row lineage, and new primitive types — work end-to-end through the patched client and the proxy’s matching v3 Avro emit paths.

Puffin Deletion Vectors

#

For format-version 3 tables, position-delete Parquets are rewritten into a single Puffin file per snapshot containing one deletion-vector-v1 blob per affected data file:

• Roaring64 portable serialisation, Iceberg-spec compatible
• Magic D1 D3 39 64, big-endian length + CRC-32 framing per spec
• Manifest entry carries file_format=puffin, content_offset, content_size_in_bytes, referenced_data_file, and record_count (= cardinality)

V2 tables keep the legacy Parquet position-delete shape — readers that only understand v2 still work.

Credential Vending

#

X-Iceberg-Access-Delegation: vended-credentials triggers a real MinIO AssumeRole call with a session policy scoped to the table’s data-file keys and its metadata/* prefix. The LoadTable response returns s3.access-key-id / s3.secret-access-key / s3.session-token / s3.credentials-expiration in the config map.

Query engines get short-lived, table-scoped credentials — no shared root keys distributed to clients.

OAuth2 + RBAC

#

POST /v1/oauth/tokens issues HMAC-signed JWTs. Middleware enforces Authorization: Bearer on every /v1/* route. Scope grammar: ns:<name>:<cap> (per-namespace) or * (superuser), where cap ∈ {r, w, rw, *}.

DUCKICELAKE_OAUTH_CLIENTS="id:secret|ns:analytics:rw,admin:secret|*"
DUCKICELAKE_REQUIRE_AUTH=1   # fail boot if no clients configured

PyIceberg consumes via credential="id:secret". DuckDB via CREATE SECRET (TYPE ICEBERG, TOKEN '<token>').

Performance and Observability

#

• In-process LRU metadata cache (DUCKICELAKE_CACHE_MAX, default 1024) — cache-hit LoadTable measured at ~349 req/s at concurrency 32
• Postgres ConnectionPool via psycopg-pool — most LoadTable work hits PG directly, bypassing the DuckDB write-conn lock
• DuckDB read pool for parallel equality-delete scans
• Per-snapshot S3 writes parallelised via thread pool; head_object before put_object skips re-uploads of byte-identical content
• Single Postgres transaction per commit via contextvars-driven shared cursor

Prometheus exposition at /metrics: per-endpoint latency histograms, request counts by status class, cache hit/miss counters, PG pool state. /healthz and /readyz for liveness and readiness probes.

The lakesh Companion

#

lakesh is a small DuckDB-powered SQL shell for Iceberg REST catalogs and DuckLake direct. Profile-based connection management, an interactive REPL with psql-style meta-commands, one-shot exec mode for scripts, and an MCP server so LLM agents can query your catalogs through the same plumbing.

It pairs naturally with duckicelake — point it at the proxy and get a familiar SQL shell over your Iceberg tables.

Getting Started

#

The entire stack — Postgres, MinIO, the proxy, and all Python dependencies — is managed by a single pixi.toml. pixi install sets everything up; the task runner handles the rest. Local and production environments are identical.

git clone https://github.com/KellerKev/duckicelake.git
cd duckicelake
pixi install
pixi run backends-up     # Postgres + MinIO
pixi run ducklake-init   # creates bucket + default namespace
pixi run serve           # Iceberg REST catalog on :8181

In another terminal:

pixi run smoke           # catalog-only smoke
pixi run duckdb-client   # full demo — 20+ assertion blocks across all features
pixi run test            # pytest integration suite (22 tests)

Teardown: pixi run backends-down.

If you want to take the full DuckLake stack further — row-level access control, S3 bucket policies, and a governed deployment on Hetzner for under 10 euros a month — the DuckLake on Hetzner with Pixi article covers the complete pixi-managed setup.

What’s Left

#

The Iceberg spec surface is effectively complete. Remaining gaps are architectural (DuckLake-blocked: true divergent branches, per-table set-location, real KMS encryption), upstream (Spark v3 writes, DuckDB iceberg-ext v3 features), and production-readiness ops (HA backends, TLS, distributed tracing, shipped Grafana dashboards, Spark/Trino integration tests).

See MISSING.md for the full punch list.

DuckIceLake is open source: github.com/KellerKev/duckicelake

Companion SQL shell: github.com/KellerKev/lakesh
